Wafer bonding is turning one memory chip into two wafers, doubling demand for bonding equipment, CMP and silicon wafers. In bonded NAND, pioneered by YMTC's Xtacking, logic and memory arrays are built on separate wafers under optimal conditions; Kioxia began in 2024, and Samsung and SK hynix are expected to adopt it in 2027. DRAM-on-Logic bonding for edge AI reaches about 1TB/s versus 50-60GB/s for LPDDR5X; Nomura sees volume in 2028. Beneficiaries include Piotech, NSIG, Dinglong and Anji. x.com x.com x.comÂ
